FYTJ 40 KF SKF
6866004381-YatakliFlanged ball bearing units
Quote and order options
SKF FYTJ 40 KF flanged ball bearing unit: bore diameter (d) 35 mm, bolt hole spacing 144 mm, pilot diameter 88.9 mm, and basic dynamic load rating C 30.7 kN.
Set the quantity and add it to your quote list, or ask our team for technical support. When you sign in with your approved business account, your own prices and stock information are also shown.
Verifying price and stock…
FYTJ 40 KF SKF technical data
- Brand
- SKF
- Category
- Bearing housings and units / Flanged bearing housings and units / Flanged ball bearing units
- Part number
- FYTJ 40 KF
- Overall length
- 100 mm
- Overall height
- 175 mm
- Overall width
- 48.25 mm
- Mounting hole spacing
- 144 mm
- Housing total width
- 36 mm
- Centering diameter
- 88.9 mm
- Adapter sleeve width
- 46 mm
- Lock nut outer diameter
- 58 mm
- Inner ring face to raceway centre
- 27.15 mm
- Bore diameter (d)
- 35 mm
- Width (B)
- 33.9 mm
- Basic dynamic load rating C
- 30.7 kN
- Basic static load rating C0
- 19 kN
- Mounting hole diameter
- 16 mm
- Fatigue load limit Pu
- 0.8 kN
- Flange width
- 16 mm
- SKU
- 6866004381-Yatakli
- HS code (6-digit)
- 848320
- CN code (8-digit)
- 84832000
- GTİP (Turkish customs tariff number, 12-digit)
- 848320000000
- Country of origin
- Sweden
- Net weight
- 1.43 kg
- Volumetric weight (desi)
- 1.4312
