FYWK 50 LTA SKF
6866004425-YatakliFlanged ball bearing units
Quote and order options
SKF FYWK 50 LTA flanged ball bearing unit: bore diameter (d) 50 mm, bolt hole spacing 111 mm, and basic dynamic load rating C 35.1 kN.
Set the quantity and add it to your quote list, or ask our team for technical support. When you sign in with your approved business account, your own prices and stock information are also shown.
Verifying price and stock…
FYWK 50 LTA SKF technical data
- Brand
- SKF
- Category
- Bearing housings and units / Flanged bearing housings and units / Flanged ball bearing units
- Part number
- FYWK 50 LTA
- Limiting speed
- 2,200 rpm
- Overall length
- 143 mm
- Overall width
- 57.6 mm
- Mounting hole spacing
- 111 mm
- Housing total width
- 43 mm
- Inner ring face to raceway centre
- 32.6 mm
- Bore diameter (d)
- 50 mm
- Width (B)
- 51.6 mm
- Basic dynamic load rating C
- 35.1 kN
- Basic static load rating C0
- 23.2 kN
- Fatigue load limit Pu
- 0.98 kN
- Flange width
- 21 mm
- SKU
- 6866004425-Yatakli
- HS code (6-digit)
- 848320
- CN code (8-digit)
- 84832000
- GTİP (Turkish customs tariff number, 12-digit)
- 848320000000
- Country of origin
- Sweden
- Net weight
- 1.25 kg
- Volumetric weight (desi)
- 1.25
