H 2305 BGL
6866016351-MansonAdapter sleeves
Quote and order options
BGL H 2305 adapter sleeve: shaft diameter 20 mm, bearing bore diameter 25 mm, thread M 25x1.5, overall length 35 mm, taper 1:12. Net weight 0.075 kg.
Set the quantity and add it to your quote list, or ask our team for technical support. When you sign in with your approved business account, your own prices and stock information are also shown.
Verifying price and stock…
H 2305 BGL technical data
- Brand
- BGL
- Category
- Accessories / Sleeves / Adapter sleeves
- Part number
- H 2305
- Lock nut outer diameter
- 38 mm
- Overall length
- 35 mm
- SKU
- 6866016351-Manson
- HS code (6-digit)
- 848299
- CN code (8-digit)
- 84829900
- GTİP (Turkish customs tariff number, 12-digit)
- 848299000019
- Country of origin
- Brazil
- Net weight
- 0.08 kg
- Volumetric weight (desi)
- 0.0617
Weight
- Catalog net weight
- 0.075 kg
Dimensions
- Compatible bearing bore
- 25 mm
- Shaft diameter
- 20 mm
Properties
- Nominal thread
- M 25x1,5 mm
- Taper ratio
- 1:12
