H 2308 BGL
6866016363-MansonAdapter sleeves
Quote and order options
BGL H 2308 adapter sleeve: shaft diameter 35 mm, bearing bore diameter 40 mm, thread M 40x1.5, overall length 46 mm, taper 1:12. Net weight 0.196 kg.
Set the quantity and add it to your quote list, or ask our team for technical support. When you sign in with your approved business account, your own prices and stock information are also shown.
Verifying price and stock…
H 2308 BGL technical data
- Brand
- BGL
- Category
- Accessories / Sleeves / Adapter sleeves
- Part number
- H 2308
- Lock nut outer diameter
- 58 mm
- Overall length
- 46 mm
- SKU
- 6866016363-Manson
- HS code (6-digit)
- 848299
- CN code (8-digit)
- 84829900
- GTİP (Turkish customs tariff number, 12-digit)
- 848299000019
- Country of origin
- Brazil
- Net weight
- 0.2 kg
- Volumetric weight (desi)
- 0.1338
Weight
- Catalog net weight
- 0.196 kg
Dimensions
- Compatible bearing bore
- 40 mm
- Shaft diameter
- 35 mm
Properties
- Nominal thread
- M 40x1,5 mm
- Taper ratio
- 1:12
