H 2317 BGL
6866016401-MansonAdapter sleeves
Quote and order options
BGL H 2317 adapter sleeve: shaft diameter 75 mm, bearing bore diameter 85 mm, thread M 85x2, overall length 82 mm, taper 1:12. Net weight 1.301 kg.
Set the quantity and add it to your quote list, or ask our team for technical support. When you sign in with your approved business account, your own prices and stock information are also shown.
Verifying price and stock…
H 2317 BGL technical data
- Brand
- BGL
- Category
- Accessories / Sleeves / Adapter sleeves
- Part number
- H 2317
- Lock nut outer diameter
- 110 mm
- Overall length
- 82 mm
- SKU
- 6866016401-Manson
- HS code (6-digit)
- 848299
- CN code (8-digit)
- 84829900
- GTİP (Turkish customs tariff number, 12-digit)
- 848299000019
- Country of origin
- Brazil
- Net weight
- 1.3 kg
- Volumetric weight (desi)
- 0.5746
Weight
- Catalog net weight
- 1.301 kg
Dimensions
- Compatible bearing bore
- 85 mm
- Shaft diameter
- 75 mm
Properties
- Nominal thread
- M 85x2 mm
- Taper ratio
- 1:12
