H 240/1060 BGL
6866016713-MansonAdapter sleeves
Quote and order options
BGL H 240/1060 adapter sleeve: shaft diameter 1000 mm, bearing bore diameter 1060 mm, thread Tr 1060x8, overall length 588 mm, taper 1:30. Net weight 710 kg.
Set the quantity and add it to your quote list, or ask our team for technical support. When you sign in with your approved business account, your own prices and stock information are also shown.
Verifying price and stock…
H 240/1060 BGL technical data
- Brand
- BGL
- Category
- Accessories / Sleeves / Adapter sleeves
- Part number
- H 240/1060
- Lock nut outer diameter
- 1,200 mm
- Overall length
- 588 mm
- SKU
- 6866016713-Manson
- HS code (6-digit)
- 848299
- CN code (8-digit)
- 84829900
- GTİP (Turkish customs tariff number, 12-digit)
- 848299000019
- Country of origin
- Brazil
- Net weight
- 710 kg
- Volumetric weight (desi)
- 342.9216
Weight
- Catalog net weight
- 710 kg
Dimensions
- Compatible bearing bore
- 1,060 mm
- Shaft diameter
- 1,000 mm
Properties
- Nominal thread
- Tr 1060x8 mm
- Taper ratio
- 1:30
