H 240/750 BGL
6866016672-MansonAdapter sleeves
Quote and order options
BGL H 240/750 adapter sleeve: shaft diameter 710 mm, bearing bore diameter 750 mm, thread Tr 750x7, overall length 460 mm, taper 1:30. Net weight 332.6 kg.
Set the quantity and add it to your quote list, or ask our team for technical support. When you sign in with your approved business account, your own prices and stock information are also shown.
Verifying price and stock…
H 240/750 BGL technical data
- Brand
- BGL
- Category
- Accessories / Sleeves / Adapter sleeves
- Part number
- H 240/750
- Lock nut outer diameter
- 870 mm
- Overall length
- 460 mm
- SKU
- 6866016672-Manson
- HS code (6-digit)
- 848299
- CN code (8-digit)
- 84829900
- GTİP (Turkish customs tariff number, 12-digit)
- 848299000019
- Country of origin
- Brazil
- Net weight
- 332.6 kg
- Volumetric weight (desi)
- 149.916
Weight
- Catalog net weight
- 332.6 kg
Dimensions
- Compatible bearing bore
- 750 mm
- Shaft diameter
- 710 mm
Properties
- Nominal thread
- Tr 750x7 mm
- Taper ratio
- 1:30
