HA 315 BGL
6866016753-MansonAdapter sleeves
Quote and order options
BGL HA 315 adapter sleeve: shaft diameter 61.91 mm, bearing bore diameter 75 mm, thread M 75x2, overall length 55 mm, taper 1:12. Net weight 0.86 kg.
Set the quantity and add it to your quote list, or ask our team for technical support. When you sign in with your approved business account, your own prices and stock information are also shown.
Verifying price and stock…
HA 315 BGL technical data
- Brand
- BGL
- Category
- Accessories / Sleeves / Adapter sleeves
- Part number
- HA 315
- Lock nut outer diameter
- 98 mm
- Overall length
- 55 mm
- SKU
- 6866016753-Manson
- HS code (6-digit)
- 848299
- CN code (8-digit)
- 84829900
- GTİP (Turkish customs tariff number, 12-digit)
- 848299000019
- Country of origin
- Brazil
- Net weight
- 0.86 kg
- Volumetric weight (desi)
- 0.3481
Weight
- Catalog net weight
- 0.86 kg
Dimensions
- Compatible bearing bore
- 75 mm
- Shaft diameter
- 61.91 mm
Properties
- Nominal thread
- M 75x2 mm
- Taper ratio
- 1:12
