KM 20 12F BGL
6866018689-SomunLock nuts
Quote and order options
BGL KM 20 12F lock nut: thread 3,918"x12F, nut outside diameter 130 mm, width 18 mm, slot depth 4 mm. Net weight 0.665 kg.
Set the quantity and add it to your quote list, or ask our team for technical support. When you sign in with your approved business account, your own prices and stock information are also shown.
Verifying price and stock…
KM 20 12F BGL technical data
- Brand
- BGL
- Category
- Accessories / Locking devices / Lock nuts
- Part number
- KM 20 12F
- Lock nut outer diameter
- 130 mm
- Lock nut width
- 18 mm
- Slot depth
- 4 mm
- SKU
- 6866018689-Somun
- HS code (6-digit)
- 731816
- CN code (8-digit)
- 73181660
- GTİP (Turkish customs tariff number, 12-digit)
- 731816600000
- Country of origin
- Brazil
- Net weight
- 0.67 kg
- Volumetric weight (desi)
- 0.285
Weight
- Catalog net weight
- 0.665 kg
Dimensions
- Chamfer diameter
- 120 mm
- Lock nut slot width
- 10 mm
- Threads per inch
- 12 1/in
Compatibility
- Compatible lock washers
- MB 20
Properties
- Nominal thread
- 3.918"x12F
