KMT 10 BGL
6866018717-SomunLock nuts
Quote and order options
BGL KMT 10 lock nut: thread M 50x1.5, nut outside diameter 75 mm, width 25 mm, slot depth 3 mm. Net weight 0.4 kg.
Set the quantity and add it to your quote list, or ask our team for technical support. When you sign in with your approved business account, your own prices and stock information are also shown.
Verifying price and stock…
KMT 10 BGL technical data
- Brand
- BGL
- Category
- Accessories / Locking devices / Lock nuts
- Part number
- KMT 10
- Lock nut outer diameter
- 75 mm
- Lock nut width
- 25 mm
- Slot depth
- 3 mm
- SKU
- 6866018717-Somun
- HS code (6-digit)
- 731816
- CN code (8-digit)
- 73181660
- GTİP (Turkish customs tariff number, 12-digit)
- 731816600000
- Country of origin
- Brazil
- Net weight
- 0.4 kg
- Volumetric weight (desi)
- 0.1354
Weight
- Catalog net weight
- 0.4 kg
Dimensions
- Lock nut projection diameter
- 68 mm
- Lock nut slot width
- 7 mm
- Locking screw tightening torque
- 8 Nm
- Spanner width across flats
- 70 mm
Properties
- Nominal thread
- M 50x1,5 mm
- Nut locking screw
- M 6
