KMT 20 BGL
6866018727-SomunLock nuts
Quote and order options
BGL KMT 20 lock nut: thread M 100x2, nut outside diameter 135 mm, width 32 mm, slot depth 4 mm. Net weight 1.26 kg.
Set the quantity and add it to your quote list, or ask our team for technical support. When you sign in with your approved business account, your own prices and stock information are also shown.
Verifying price and stock…
KMT 20 BGL technical data
- Brand
- BGL
- Category
- Accessories / Locking devices / Lock nuts
- Part number
- KMT 20
- Lock nut outer diameter
- 135 mm
- Lock nut width
- 32 mm
- Slot depth
- 4 mm
- SKU
- 6866018727-Somun
- HS code (6-digit)
- 731816
- CN code (8-digit)
- 73181660
- GTİP (Turkish customs tariff number, 12-digit)
- 731816600000
- Country of origin
- Brazil
- Net weight
- 1.26 kg
- Volumetric weight (desi)
- 0.4164
Weight
- Catalog net weight
- 1.26 kg
Dimensions
- Lock nut projection diameter
- 125 mm
- Lock nut slot width
- 10 mm
- Locking screw tightening torque
- 35 Nm
Properties
- Nominal thread
- M 100x2 mm
- Nut locking screw
- M 10
