KMT 9 BGL
6866018716-SomunLock nuts
Quote and order options
BGL KMT 9 lock nut: thread M 45x1.5, nut outside diameter 70 mm, width 22 mm, slot depth 2.5 mm. Net weight 0.29 kg.
Set the quantity and add it to your quote list, or ask our team for technical support. When you sign in with your approved business account, your own prices and stock information are also shown.
Verifying price and stock…
KMT 9 BGL technical data
- Brand
- BGL
- Category
- Accessories / Locking devices / Lock nuts
- Part number
- KMT 9
- Lock nut outer diameter
- 70 mm
- Lock nut width
- 22 mm
- Slot depth
- 2.5 mm
- SKU
- 6866018716-Somun
- HS code (6-digit)
- 731816
- CN code (8-digit)
- 73181660
- GTİP (Turkish customs tariff number, 12-digit)
- 731816600000
- Country of origin
- Brazil
- Net weight
- 0.29 kg
- Volumetric weight (desi)
- 0.1134
Weight
- Catalog net weight
- 0.29 kg
Dimensions
- Lock nut projection diameter
- 64 mm
- Lock nut slot width
- 6 mm
- Locking screw tightening torque
- 8 Nm
- Spanner width across flats
- 65 mm
Properties
- Nominal thread
- M 45x1,5 mm
- Nut locking screw
- M 6
