OH 24140H BGL
6866017719-MansonAdapter sleeves
Quote and order options
BGL OH 24140H hydraulic adapter sleeve; shaft diameter 180 mm, bearing bore diameter 200 mm, thread M 200x3, overall length 185 mm, taper 1:30. Net weight 13 kg.
Set the quantity and add it to your quote list, or ask our team for technical support. When you sign in with your approved business account, your own prices and stock information are also shown.
Verifying price and stock…
OH 24140H BGL technical data
- Brand
- BGL
- Category
- Accessories / Sleeves / Adapter sleeves
- Part number
- OH 24140H
- Lock nut outer diameter
- 250 mm
- Overall length
- 185 mm
- SKU
- 6866017719-Manson
- HS code (6-digit)
- 848299
- CN code (8-digit)
- 84829900
- GTİP (Turkish customs tariff number, 12-digit)
- 848299000019
- Country of origin
- Brazil
- Net weight
- 13 kg
- Volumetric weight (desi)
- 4.9815
Weight
- Catalog net weight
- 13 kg
Dimensions
- Compatible bearing bore
- 200 mm
- Shaft diameter
- 180 mm
Properties
- Nominal thread
- M 200x3 mm
- Oil injection hole thread
- M6
- Taper ratio
- 1:30
