OHE 3032HE BGL
6866017612-MansonAdapter sleeves
Quote and order options
BGL OHE 3032HE hydraulic adapter sleeve; shaft diameter 139.7 mm, bearing bore diameter 160 mm, thread M 160x3, overall length 93 mm, taper 1:12.
Set the quantity and add it to your quote list, or ask our team for technical support. When you sign in with your approved business account, your own prices and stock information are also shown.
Verifying price and stock…
OHE 3032HE BGL technical data
- Brand
- BGL
- Category
- Accessories / Sleeves / Adapter sleeves
- Part number
- OHE 3032HE
- Lock nut outer diameter
- 210 mm
- Overall length
- 93 mm
- SKU
- 6866017612-Manson
- HS code (6-digit)
- 848299
- CN code (8-digit)
- 84829900
- GTİP (Turkish customs tariff number, 12-digit)
- 848299000019
- Country of origin
- Brazil
- Net weight
- 6 kg
- Volumetric weight (desi)
- 1.9926
Weight
- Catalog net weight
- 6.001 kg
Dimensions
- Compatible bearing bore
- 160 mm
- Shaft diameter
- 139.7 mm
Properties
- Nominal thread
- M 160x3 mm
- Oil injection hole thread
- M6
- Taper ratio
- 1:12
