OHE 3036HE BGL
6866017663-MansonAdapter sleeves
Quote and order options
BGL OHE 3036HE hydraulic adapter sleeve; shaft diameter 165.1 mm, bearing bore diameter 180 mm, thread M 180x3, overall length 109 mm, taper 1:12.
Set the quantity and add it to your quote list, or ask our team for technical support. When you sign in with your approved business account, your own prices and stock information are also shown.
Verifying price and stock…
OHE 3036HE BGL technical data
- Brand
- BGL
- Category
- Accessories / Sleeves / Adapter sleeves
- Part number
- OHE 3036HE
- Lock nut outer diameter
- 230 mm
- Overall length
- 109 mm
- SKU
- 6866017663-Manson
- HS code (6-digit)
- 848299
- CN code (8-digit)
- 84829900
- GTİP (Turkish customs tariff number, 12-digit)
- 848299000019
- Country of origin
- Brazil
- Net weight
- 6.53 kg
- Volumetric weight (desi)
- 2.6875
Weight
- Catalog net weight
- 6.533 kg
Dimensions
- Compatible bearing bore
- 180 mm
- Shaft diameter
- 165.1 mm
Properties
- Nominal thread
- M 180x3 mm
- Oil injection hole thread
- M6
- Taper ratio
- 1:12
