OHE 3134HE BGL
6866017646-MansonAdapter sleeves
Quote and order options
BGL OHE 3134HE hydraulic adapter sleeve; shaft diameter 152.4 mm, bearing bore diameter 170 mm, thread M 170x3, overall length 122 mm, taper 1:12.
Set the quantity and add it to your quote list, or ask our team for technical support. When you sign in with your approved business account, your own prices and stock information are also shown.
Verifying price and stock…
OHE 3134HE BGL technical data
- Brand
- BGL
- Category
- Accessories / Sleeves / Adapter sleeves
- Part number
- OHE 3134HE
- Lock nut outer diameter
- 220 mm
- Overall length
- 122 mm
- SKU
- 6866017646-Manson
- HS code (6-digit)
- 848299
- CN code (8-digit)
- 84829900
- GTİP (Turkish customs tariff number, 12-digit)
- 848299000019
- Country of origin
- Brazil
- Net weight
- 7.41 kg
- Volumetric weight (desi)
- 2.7264
Weight
- Catalog net weight
- 7.411 kg
Dimensions
- Compatible bearing bore
- 170 mm
- Shaft diameter
- 152.4 mm
Properties
- Nominal thread
- M 170x3 mm
- Oil injection hole thread
- M6
- Taper ratio
- 1:12
