OHE 3160HTL BGL
6866017817-MansonAdapter sleeves
Quote and order options
BGL OHE 3160HTL hydraulic adapter sleeve: shaft diameter 279.4 mm, bearing bore diameter 300 mm, thread Tr 300x4, overall length 210 mm, taper 1:12.
Set the quantity and add it to your quote list, or ask our team for technical support. When you sign in with your approved business account, your own prices and stock information are also shown.
Verifying price and stock…
OHE 3160HTL BGL technical data
- Brand
- BGL
- Category
- Accessories / Sleeves / Adapter sleeves
- Part number
- OHE 3160HTL
- Lock nut outer diameter
- 360 mm
- Overall length
- 210 mm
- SKU
- 6866017817-Manson
- HS code (6-digit)
- 848299
- CN code (8-digit)
- 84829900
- GTİP (Turkish customs tariff number, 12-digit)
- 848299000019
- Country of origin
- Brazil
- Net weight
- 27.6 kg
- Volumetric weight (desi)
- 11.0707
Weight
- Catalog net weight
- 27.6 kg
Dimensions
- Compatible bearing bore
- 300 mm
- Shaft diameter
- 279.4 mm
Properties
- Nominal thread
- Tr 300x4 mm
- Oil injection hole thread
- M6
- Taper ratio
- 1:12
