UCFB 208/H SKF
6866014111-YatakliFlanged ball bearing units
Quote and order options
SKF UCFB 208/H flanged ball bearing unit; bore diameter (d) 40 mm, basic dynamic load rating C 30.7 kN, bolt hole diameter 11 mm.
Set the quantity and add it to your quote list, or ask our team for technical support. When you sign in with your approved business account, your own prices and stock information are also shown.
Verifying price and stock…
UCFB 208/H SKF technical data
- Brand
- SKF
- Category
- Bearing housings and units / Flanged bearing housings and units / Flanged ball bearing units
- Part number
- UCFB 208/H
- Overall length
- 100 mm
- Overall height
- 164 mm
- Overall width
- 51.2 mm
- Set screw hole distance
- 8 mm
- Flange overall length
- 78 mm
- Housing total width
- 35.5 mm
- Inner ring face to raceway centre
- 30.2 mm
- Bore diameter (d)
- 40 mm
- Width (B)
- 49.2 mm
- Basic dynamic load rating C
- 30.7 kN
- Basic static load rating C0
- 19 kN
- Mounting hole diameter
- 11 mm
- Fatigue load limit Pu
- 0.8 kN
- Flange width
- 16 mm
- SKU
- 6866014111-Yatakli
- HS code (6-digit)
- 848320
- CN code (8-digit)
- 84832000
- GTİP (Turkish customs tariff number, 12-digit)
- 848320000000
- Country of origin
- Sweden
- Net weight
- 1.61 kg
- Volumetric weight (desi)
- 1.6112
