UCFN 207 2F
6866015137-YatakliFlanged ball bearing units
Quote and order options
Z&R UCFN 207 2F mounted bearing unit. Bore diameter 35 mm, width 42.9 mm. Basic dynamic load rating 25.5 kN, basic static load rating 15.3 kN. Weight 1.4 kg.
Set the quantity and add it to your quote list, or ask our team for technical support. When you sign in with your approved business account, your own prices and stock information are also shown.
Verifying price and stock…
UCFN 207 2F technical data
- Brand
- Z&R
- Category
- Bearing housings and units / Flanged bearing housings and units / Flanged ball bearing units
- Part number
- UCFN 207 2F
- Overall length
- 118 mm
- Overall width
- 44.4 mm
- Mounting hole spacing
- 92 mm
- Housing total width
- 34 mm
- Bore diameter (d)
- 35 mm
- Width (B)
- 42.9 mm
- Basic dynamic load rating C
- 25.5 kN
- Housing flange thickness
- 13 mm
- Basic static load rating C0
- 15.3 kN
- Mounting hole diameter
- 14 mm
- Fatigue load limit Pu
- 0.643 kN
- SKU
- 6866015137-Yatakli
- HS code (6-digit)
- 848320
- CN code (8-digit)
- 84832000
- GTİP (Turkish customs tariff number, 12-digit)
- 848320000000
- Country of origin
- China
- Net weight
- 1.4 kg
