UKFB 209 K/H SKF
6866014291-YatakliFlanged ball bearing units
Quote and order options
SKF UKFB 209 K/H flanged ball bearing unit; bore diameter (d) 40 mm, basic dynamic load rating C 33.2 kN, bolt hole diameter 11 mm.
Set the quantity and add it to your quote list, or ask our team for technical support. When you sign in with your approved business account, your own prices and stock information are also shown.
Verifying price and stock…
UKFB 209 K/H SKF technical data
- Brand
- SKF
- Category
- Bearing housings and units / Flanged bearing housings and units / Flanged ball bearing units
- Part number
- UKFB 209 K/H
- Overall length
- 106 mm
- Overall height
- 176 mm
- Overall width
- 48.75 mm
- Flange overall length
- 80 mm
- Housing total width
- 37 mm
- Adapter sleeve width
- 50 mm
- Lock nut outer diameter
- 65 mm
- Inner ring face to raceway centre
- 28.75 mm
- Bore diameter (d)
- 40 mm
- Width (B)
- 35 mm
- Basic dynamic load rating C
- 33.2 kN
- Basic static load rating C0
- 21.6 kN
- Mounting hole diameter
- 11 mm
- Fatigue load limit Pu
- 0.915 kN
- Flange width
- 18 mm
- SKU
- 6866014291-Yatakli
- HS code (6-digit)
- 848320
- CN code (8-digit)
- 84832000
- GTİP (Turkish customs tariff number, 12-digit)
- 848320000000
- Country of origin
- Sweden
- Net weight
- 1.73 kg
- Volumetric weight (desi)
- 1.731
