KM 13 18F BGL
6866018682-SomunLock nuts
Quote and order options
BGL KM 13 18F lock nut: thread 2,548"x18F, nut outside diameter 85 mm, width 12 mm, slot depth 3 mm. Net weight 0.19 kg.
Set the quantity and add it to your quote list, or ask our team for technical support. When you sign in with your approved business account, your own prices and stock information are also shown.
Verifying price and stock…
KM 13 18F BGL technical data
- Brand
- BGL
- Category
- Accessories / Locking devices / Lock nuts
- Part number
- KM 13 18F
- Lock nut outer diameter
- 85 mm
- Lock nut width
- 12 mm
- Slot depth
- 3 mm
- SKU
- 6866018682-Somun
- HS code (6-digit)
- 731816
- CN code (8-digit)
- 73181660
- GTİP (Turkish customs tariff number, 12-digit)
- 731816600000
- Country of origin
- Brazil
- Net weight
- 0.19 kg
- Volumetric weight (desi)
- 0.1176
Weight
- Catalog net weight
- 0.19 kg
Dimensions
- Chamfer diameter
- 79 mm
- Lock nut slot width
- 7 mm
- Threads per inch
- 18 1/in
Compatibility
- Compatible lock washers
- MB 13
Properties
- Nominal thread
- 2.548"x18F
