KM 17 12F BGL
6866018686-SomunLock nuts
Quote and order options
BGL KM 17 12F lock nut: thread 3,340"x12F, nut outside diameter 110 mm, width 16 mm, slot depth 3.5 mm. Net weight 0.41 kg.
Set the quantity and add it to your quote list, or ask our team for technical support. When you sign in with your approved business account, your own prices and stock information are also shown.
Verifying price and stock…
KM 17 12F BGL technical data
- Brand
- BGL
- Category
- Accessories / Locking devices / Lock nuts
- Part number
- KM 17 12F
- Lock nut outer diameter
- 110 mm
- Lock nut width
- 16 mm
- Slot depth
- 3.5 mm
- SKU
- 6866018686-Somun
- HS code (6-digit)
- 731816
- CN code (8-digit)
- 73181660
- GTİP (Turkish customs tariff number, 12-digit)
- 731816600000
- Country of origin
- Brazil
- Net weight
- 0.41 kg
- Volumetric weight (desi)
- 0.2028
Weight
- Catalog net weight
- 0.41 kg
Dimensions
- Chamfer diameter
- 102 mm
- Lock nut slot width
- 8 mm
- Threads per inch
- 12 1/in
Compatibility
- Compatible lock washers
- MB 17
Properties
- Nominal thread
- 3.340"x12F
