OH 241/900H BGL
6866018014-MansonAdapter sleeves
Quote and order options
BGL OH 241/900H hydraulic adapter sleeve: shaft diameter 850 mm, bearing bore diameter 900 mm, thread Tr 900x7, overall length 685 mm, taper 1:30. Net weight 760 kg.
Set the quantity and add it to your quote list, or ask our team for technical support. When you sign in with your approved business account, your own prices and stock information are also shown.
Verifying price and stock…
OH 241/900H BGL technical data
- Brand
- BGL
- Category
- Accessories / Sleeves / Adapter sleeves
- Part number
- OH 241/900H
- Lock nut outer diameter
- 1,120 mm
- Overall length
- 685 mm
- SKU
- 6866018014-Manson
- HS code (6-digit)
- 848299
- CN code (8-digit)
- 84829900
- GTİP (Turkish customs tariff number, 12-digit)
- 848299000019
- Country of origin
- Brazil
- Net weight
- 760 kg
- Volumetric weight (desi)
- 345.7793
Weight
- Catalog net weight
- 760 kg
Dimensions
- Compatible bearing bore
- 900 mm
- Shaft diameter
- 850 mm
Properties
- Nominal thread
- Tr 900x7 mm
- Oil injection hole thread
- 1/8 BSP
- Taper ratio
- 1:30
