H 322 E BGL
6866016422-MansonAdapter sleeves
Quote and order options
BGL H 322 E adapter sleeve: shaft diameter 100 mm, bearing bore diameter 110 mm, thread M 110x2, overall length 77 mm, taper 1:12. Net weight 2 kg.
Set the quantity and add it to your quote list, or ask our team for technical support. When you sign in with your approved business account, your own prices and stock information are also shown.
Verifying price and stock…
H 322 E BGL technical data
- Brand
- BGL
- Category
- Accessories / Sleeves / Adapter sleeves
- Part number
- H 322 E
- Lock nut outer diameter
- 145 mm
- Overall length
- 77 mm
- SKU
- 6866016422-Manson
- HS code (6-digit)
- 848299
- CN code (8-digit)
- 84829900
- GTİP (Turkish customs tariff number, 12-digit)
- 848299000019
- Country of origin
- Brazil
- Net weight
- 2 kg
- Volumetric weight (desi)
- 0.8803
Weight
- Catalog net weight
- 2 kg
Dimensions
- Compatible bearing bore
- 110 mm
- Shaft diameter
- 100 mm
Properties
- Nominal thread
- M 110x2 mm
- Nut locking screw
- M 8 mm
- Taper ratio
- 1:12
