HS 318 E BGL
6866017120-MansonAdapter sleeves
Quote and order options
BGL HS 318 E adapter sleeve: shaft diameter 79.37 mm, bearing bore diameter 90 mm, thread M 90x2, overall length 65 mm, taper 1:12. Net weight 1.326 kg.
Set the quantity and add it to your quote list, or ask our team for technical support. When you sign in with your approved business account, your own prices and stock information are also shown.
Verifying price and stock…
HS 318 E BGL technical data
- Brand
- BGL
- Category
- Accessories / Sleeves / Adapter sleeves
- Part number
- HS 318 E
- Lock nut outer diameter
- 120 mm
- Overall length
- 65 mm
- SKU
- 6866017120-Manson
- HS code (6-digit)
- 848299
- CN code (8-digit)
- 84829900
- GTİP (Turkish customs tariff number, 12-digit)
- 848299000019
- Country of origin
- Brazil
- Net weight
- 1.33 kg
- Volumetric weight (desi)
- 0.5553
Weight
- Catalog net weight
- 1.326 kg
Dimensions
- Compatible bearing bore
- 90 mm
- Shaft diameter
- 79.37 mm
Properties
- Nominal thread
- M 90x2 mm
- Nut locking screw
- M 8 mm
- Taper ratio
- 1:12
